詳細介紹 / Details
180℃高溫水溫機特點：
1.管路防爆裝置
Explosion/proof equipment for pipelines
2.吹氣回水功能（選購）
Air blowing and return water function（optional)
3.回水溫度顯示表
Thermometer for return water
4.開機自動排氣功能
Automatic air-exhausting function after startup
5.加熱功率切換功能
Switchover of heating power
6.熱水BY-PASS泄壓回路
BY-PASS pressure release loop for hot water
7.多點溫度控制機組可訂作
Customizable multi-point temperature control unit
8.水泵馬力和加熱功率可訂作
Customizable horsepower and heating power of oil pump
9.即實時冷卻關機功能(選購)
Instant cooling return oil shut-down function (optional)
10.控制方式: 采用進口微電腦或(選購)PLC控制
Control mode: imported microcomputer or PLC (optional)
11.溫度控制范圍: 進水溫+25℃→120℃
Range of temperature control: +25℃→120℃ for incoming water
12.隔離式電器控制箱. 延長電器使用年限
Isolated electric box for longer services lives of electric appliances
13.RS485通訊功能, 實現自動化管理.(選購)
RS485 communication function for automated management (optional)
14.304不銹鋼一體管路,減少管阻及銹垢
304 stainless steel integrated pipelines for less pipe resistance and rust
15.電器采用OMRON. FUJI. TE. LG.MOELLR.ABB.WEST
Brands OMRON, FUJI, TE and LG.MOELLER.ABB and WEST for electric appliances
16.安全保護完善,故障顯示, 維修.保養無需專業人員
Perfect safety protection, fault display, easy repair and maintenance even without professionals
應用范圍：射出成型模具控溫、押出成型、輥輪加溫、橡膠機械溫度控制、導光板、光學鏡頭、光碟、連接器之射出成型
|
模型Model |
單位UNIT |
TWA-05 |
TWP-05 |
TWA-10 |
TWP-10 |
TWP-20 |
TWP-30 |
||||
|
溫控范圍 Control range |
℃ |
120℃ |
|||||||||
|
溫控精度Temp.control accuracy |
℃ |
PID±1℃ |
|||||||||
|
電源 Power supply |
|
AC 3φ380V50HZ（or other)或其它 |
|||||||||
|
傳熱媒體 Heat.transfer medium |
|
水 Water |
|||||||||
|
冷卻方式 Cooling method |
|
直接冷卻Direct cooling（間接冷卻可定制） |
|||||||||
|
加熱能量Heating capacity |
KW |
6 |
9 |
9 |
9 |
12 |
12 |
|
|||
|
泵浦馬力（功率）Horsepower of Pump |
HP/KW |
0.5/0.37 |
1/0.75 |
0.5/0.37 |
1/0.75 |
2/1.5 |
3/2.25 |
|
|||
|
泵浦工作流量 Working flow of pump |
L/MIN |
35 |
100 |
35 |
100 |
180 |
220 |
|
|||
|
泵浦工作壓力Working pressure of pump |
KG/C㎡ |
2 |
2.2 |
2.2 |
2.2 |
2.4 |
3.2 |
|
|||
|
大電力消耗Maximum power consumption |
KW |
6.5 |
13 |
6.5 |
13 |
14 |
15 |
|
|||
|
警報功能 Alarm function |
|
缺相/缺水/超溫/過載/反轉 |
|
||||||||
|
冷卻水配管Cooing water pipework |
INCH |
1/2 |
1/2 |
1/2 |
1/2 |
1/2 |
1/2 |
|
|||
|
循環水配管Circulating water pipework |
INCH |
3/8x2 |
3/8x4 |
3/8x2 |
3/8x4 |
3/8x4 |
(3/8x4)x4 |
|
|||
|
外型尺寸LxWxH |
MM |
780x320x660 |
800x320x660 |
800x320x660 |
800x320x660 |
800x320x660 |
800x320x660 |
|
|||
|
重量 Weighht |
KG |
70 |
0 |
70 |
80 |
92 |
95 |
|
|||
|
以上規格如有變更，恕不另行通知，特殊規格及多機一體機型可定制。Special design upon request |
|
||||||||||
